Los diferentes modelos
disponibles pueden obtenerse combinando las medidas descriptas en el plano y las tablas
que se describen a continuación: |
|
| CUERPO |
A |
B |
C |
D |
E |
F |
G |
H |
K |
| 56 |
90 |
71 |
36 |
9 |
20 |
3 |
10^2 |
56 |
7 |
| 63 |
100 |
80 |
40 |
11 |
23 |
4 |
12^5 |
63 |
7 |
| 71 |
112 |
90 |
45 |
14 |
30 |
5 |
16 |
71 |
8 |
| 80 |
125 |
100 |
50 |
19 |
40 |
6 |
21.5 |
80 |
10 |
| 90 |
140 |
125 |
56 |
24 |
50 |
8 |
27 |
90 |
10 |
|
| 2 POLOS -
3000 RPM |
| CUERPO |
POTENCIA |
| 56 |
1/8 |
| 63 |
1/6 |
| 63 |
1/4 |
| 71 |
1/2 |
| 71 |
3/4 |
| 80 |
1 |
| 90 |
2 |
| 4 POLOS -
1500 RPM |
| CUERPO |
POTENCIA |
| 56 |
1/10 |
| 63 |
1/6 |
| 63 |
1/4 |
| 71 |
1/3 |
| 71 |
1/2 |
| 80 |
3/4 |
| 90 |
1 1/2 |
| 6 POLOS
-1000 RPM |
| CUERPO |
POTENCIA |
| 56 |
1/2 |
| 63 |
1/10 |
| 71 |
1/4 |
| 80 |
1/2 |
| 90 |
1 |
| 8 POLOS-750
RPM |
| CUERPO |
POTENCIA |
| 56 |
1/15 |
| 63 |
1/10 |
| 71 |
1/8 |
| 80 |
1/4 |
| 90 |
1/2 |
|
